Quick Reference for Input Parameters

Type:

• EMS Code - Fixed dimensions
• BOBST Code - Fixed dimensions
• Custom Code - Variable dimension

Code:

Code number. This number will be converted into a binary code (Max 32 Bit).

Refer to the Code Type specification for more details.

Options:

• xwidth - Width for wide bar in mm for custom symbol type
• ywidth - Width for spacing in mm for custom symbol type
• zwidth - Width for narrow in mm bar for custom symbol type
• height - Set symbol height in mm
• width - Force symbol to given width in mm
• lateralmsb - Add lateral die cut mark at the beginning
• laterallsb - Add a lateral die cut mark at the end
• lsbgap, msbgap - width of the space between bar and die cutmark
• inkspread -
• includetext - Displays code as readable text
• textpos -
• textxpost -
• textfont -
• textsize -
• showborder -
• borderwidth -
• borderleft/right/top/bottom -
